Spacing of components fixed but adjustable.
36 Ferrite magnets with poles all pointing in the same direction.
Center disc floating on loose fitting axle.
Sheet steel backing plate. Ferrite magnets held in place by magnetic attraction
72 Rare earth magnets epoxied onto central disc at same diameter as opposing ferrite magnets
Angled view of complete assembly
